How Sterilization Methods Affect Medical Device Plastic Materials

To protect patients, medical instruments must be free from viable microorganisms. However, the very methods used to achieve sterility can have profound effects on the plastic materials from which these devices are made. Understanding the interplay between a polymer's properties and the chosen sterilization technique is fundamental to designing a safe, reliable, and effective medical product. Three of the most prevalent sterilization methods in the medical industry are steam sterilization (autoclave), gamma irradiation, and ethylene oxide (EtO) gas. Each method presents a unique set of challenges and compatibilities, depending on the type of plastic resin used. Choosing the right material early in Design for Injection Molding (DfIM) or DFM for Medical Devices ensures optimal device performance and longevity.

Read More About Nylon (Polyamide): Durable and Versatile for Many Applications

Steam Sterilization (Autoclave): The Test of Heat and Pressure

Steam autoclaving is a common and effective sterilization method that utilizes high-pressure steam to kill microorganisms. The process typically involves exposing devices to saturated steam at temperatures ranging from 250°F (121°C) to 270°F (132°C). This combination of heat and moisture is highly effective but also places significant stress on plastic components. The primary consideration for any material destined for an autoclave is its ability to withstand high temperatures without softening, warping, or degrading—a critical aspect of plastic part design optimization in medical applications.

Some polymers are well-suited for this environment. High-performance plastics such as Polyetheretherketone (PEEK) and Polyetherimide (PEI), known by the trade name Ultem, exhibit remarkable stability and can endure numerous autoclave cycles without significant loss of mechanical properties. Polypropylene (PP) is another frequently used resin that can resist autoclave temperatures, making it a cost-effective choice for many applications. Certain grades of silicone also perform well under these conditions.

Conversely, many common plastics are not suitable for steam sterilization. Materials like Polycarbonate (PC) can be susceptible to hydrolysis from the hot steam, a chemical breakdown that can lead to crazing, cloudiness, and a reduction in strength over repeated cycles. Low-Density Polyethylene (LDPE) and High-Density Polyethylene (HDPE) generally have melting points that are too low for the process. Therefore, a careful evaluation of a material's thermal properties is a prerequisite for any device intended for autoclave sterilization—a crucial step in design for manufacturing solutions.

Gamma Irradiation: A High-Energy Approach

Gamma irradiation is a low-temperature sterilization method that uses high-energy photons, typically from a Cobalt-60 source, to disrupt the DNA of microorganisms, rendering them unable to reproduce. Because it does not involve high temperatures, it can be used for many heat-sensitive materials. However, the high-energy radiation is not without its own effects on polymers. When gamma rays pass through a plastic, they can cause one of two primary reactions in the polymer chains: chain scission (breaking of the polymer chains) or cross-linking (formation of new bonds between chains).

These molecular-level changes can manifest in several ways. One of the most noticeable effects is discoloration. Polycarbonate (PC) and Polypropylene (PP) are particularly known to yellow after exposure to gamma radiation. To combat this, material suppliers have developed radiation-stabilized grades that are formulated to minimize this color shift. Beyond aesthetics, gamma irradiation can alter a material's mechanical properties. For some plastics, the process can lead to embrittlement, reducing their durability and impact resistance. Materials like Polytetrafluoroethylene (PTFE), commonly known as Teflon, can degrade significantly and are generally not compatible with this method. Despite these challenges, many polymers, including polyethylene and polystyrene, are routinely and successfully sterilized using gamma irradiation. Implementing DFM development services helps identify these material-specific limitations early in product design.

Ethylene Oxide (EtO) Sterilization: The Gentle Gas

Ethylene Oxide (EtO) sterilization is a low-temperature gas process that is highly effective and compatible with a vast array of materials, making it a go-to method for devices that are sensitive to heat or radiation. The process involves exposing devices to EtO gas in a sealed chamber with controlled humidity. The gas molecules interact with the cellular proteins and DNA of microorganisms, preventing them from reproducing.

Due to its gentle nature, EtO is suitable for nearly all common medical-grade plastics, including PVC, Polycarbonate (PC), Polyethylene (PE), and ABS. This broad compatibility makes it an ideal choice for complex medical devices, pre-filled syringes, and products containing electronic components. The primary consideration with EtO sterilization is not material degradation but rather the absorption and retention of the gas by the plastic. EtO is a toxic and carcinogenic substance, so after the sterilization cycle, devices must undergo an aeration process to allow any residual gas to dissipate to safe levels. Some materials, such as certain silicones and polyurethanes, may have a higher affinity for absorbing the gas, requiring longer aeration times to meet safety standards. Advanced design for additive manufacturing (DfAM) can ensure device geometry accommodates these aeration requirements.

Choosing the appropriate material for a medical device requires a deep understanding of its intended use, its required physical properties, and the sterilization method it must withstand. The decision impacts the device's performance, safety, and longevity. A thorough analysis of material compatibility is a fundamental aspect of patient safety and product success. Utilizing plastic injection mold design services in the early stages can save time, reduce costs, and prevent costly material failures during sterilization.

At Aprios, we have extensive experience working with a wide range of medical-grade resins and understand the intricate relationship between material selection and sterilization compatibility. Our team can guide you through the process of choosing the optimal plastic for your device to ensure it maintains its integrity and performance after sterilization. If you're ready to discuss your next medical device project, contact Aprios today to learn how we can support you from concept to production.
